RANGE OF PIN PUNCHES

For the AR-15 series of rifles.

AR-15 Take Down Punch Guide

GUN-SMITH PIN PUNCHES

Two Piece AR M4 M16 Rifle Series Pivot and Roll Pin Steel ToolTWO PIECE SET ~ SILVER

£6.00p per set

£4.80p per set

Steel construction ~ silver.

2 & 2.4 inches / 50mm & 60mm long.

Weighs 24 grams.
Two Piece AR M4 M16 Rifle Series Spring, Detent and Roll Pin Steel ToolTWO PIECE SET ~ BLACK

£7.20p per set

£6.00p per set

Steel construction ~ black.

1.6 & 2.2 inches / 41mm & 56mm long.

Weighs 18 grams.
Four Piece AR M4 M16 Rifle Series Take Down Steel Pin PunchesFOUR PIECE SET ~ STEEL

£9.60p per set

£7.20p per set

Steel construction.

3.5 inches / 88mm long.

Weighs 70 grams.
Four Piece AR M4 M16 Rifle Series Take Down Stainless Steel Pin PunchesFOUR PIECE SET ~ STAINLESS STEEL

£9.60p per set

£7.20p per set

Stainless steel construction.

2.7 inches / 70mm long.

Weighs 48 grams.
Set of Four AR-15 M4 M16 Rifle Series Take-Down Pin PunchesNINE PIECE SET ~ IN ROLL

£19.20p per set

£18.00p per set

Steel construction.

Range from 2.8 to 6.3" / 72 to 160mm long.

Weighs 358 grams.
AR-15 M4 M16 Rifle Series Take Down Pin PunchesNINE PIECE SET

£21.60p per set

£15.00p per set

Stainless steel and brass construction.

3 inches / 76mm long.

Weighs 255 grams.
Condition: New

General pin punch information:

Take down pin sets for AR series of rifles.

Knurled finger grips.

The 1/16" ~ bolt ejector/charging handle.
The 5/64" ~ gas tube.
The 3/32" ~ bolt catch/forward assist retaining.
The 1/8" ~ trigger guard.

TWO PIECE SET ~ SILVER

Spring, detent / roll pin tool.

Made from high-quality steel with a zinc-plated finish, for rust prevention.

The two piece design, inserts and holds the detent and spring while the pivot pin is pushed in.

Aids in the faster installation / removal of the pivot spring and detent.

It also works as a roll pin punch and starter for the lower receiver roll pins.

Complete with keyring for safe storage.

TWO PIECE SET ~ BLACK

Spring, detent / roll pin tool.

Made from high-quality steel with a matt black oxide finish, for rust prevention.

Knurled grip section.

Aids in the faster installation / removal of the pivot spring and detent.

It also works as a roll pin punch and starter for the lower receiver roll pins.

FOUR PIECE SET ~ STEEL

The hollow end design helps to prevent damage caused from slipping whilst getting the pins started.

Black hardened steel set ~ 1/16", 5/64", 3/32", 1/8".

FOUR PIECE SET ~ STAINLESS STEEL

The hollow end design helps to prevent damage caused from slipping whilst getting the pins started.

Stainless steel set ~ 1/8", 5/32", 3/16", 7/32".

NINE PIECE SET ~ IN ROLL

Round head pin punches.

Made from 40CR steel.

Colour ~ black and silver.

Sizes ~ 1/16", 5/64", 3/32", 1/8", 5/32", 3/16", 7/32", 1/4", 5/16".

Complete in a handy red carry roll pouch.

NINE PIECE SET

The two smallest punches are made from stainless steel, and the others are brass.

Sizes:
Stainless steel ~ 1/16", 3/32".
Brass ~ 1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16".

Please Note: pin punches are generally considered a consumable product, they are not indestructible.

They will bend eventually, and faster if used on a stubborn pin.

It's best to use a tapered / drift starter pin punch in this case.

Usually it's extra hits rather than power of the hit that works best.

Then the correct weight of hammer is also an important factor.

Also available ~ Gunsmith Hammers.

TWO PIECE SET ~ SILVER:

Two Piece AR M4 M16 Rifle Series Pivot and Roll Pin Steel Tool

TWO PIECE SET ~ BLACK:

Two Piece AR M4 M16 Rifle Series Spring, Detent and Roll Pin Steel Tool

FOUR PIECE SET ~ STEEL:

Set of Four AR M4 M16 Rifle Series Take Down Steel Pin Punches

FOUR PIECE SET ~ STAINLESS STEEL:

Four Piece AR M4 M16 Rifle Series Take Down Stainless Steel Pin Punches

NINE PIECE SET ~ IN ROLL:

Set of Four AR-15 M4 M16 Rifle Series Take-Down Pin Punches in Red Roll

NINE PIECE SET:

Two AR-15 M4 M16 Rifle Series Take Down Pin Punches
